Removal steps of the LCD unit
Step Screw (quantity) Color
Torque
4
M 2.5 × 4 mm, flat-head, nylon-coated (6) Silver
0.29±0.03 Nm
(3.0±0.3 kgf-cm)
When installing: Ensure that the connectors are attached firmly.
1220 Keyboard bezel assembly with keyboard
For access, remove these FRUs:
• “1010 Base cover assembly” on page 59
• “1020 Built-in battery” on page 60
• “1030 Thermal bracket (for selected models)” on page 61
• “1040 M.2 solid-state drive and thermal pad” on page 62
• “1050 5G Wireless WAN card and 5G mmWave Wireless WAN card (for selected models)” on page 63
• “1060 Heatsink assembly” on page 65
• “1070 Power button module with or without fingerprint reader” on page 66
• “1080 Speakers assembly” on page 67
• “1090 SIM card board and SIM card board cable” on page 68
Chapter 8. Removing or replacing a FRU 83
