Table 8. System board connector and cable guide (continued)
No.
Connector/feature
Internal cable required
Cable connection
7
P-sensor connector (internal) P-sensor cable The wireless WAN antennas kits
come with the cable. Connect the
cables to the connectors.
8
Trackpad connector (internal) Trackpad cable Connect one end to the trackpad
module and the other end to this
connector.
9
Keyboard connector (internal) Keyboard assembly cable The battery comes with the cable.
Connect the cable to this
connector.
10
Battery connector (internal) No The battery comes with the cable.
Connect the cable to this
connector.
11
Wireless-WAN-card slot (internal) No Insert a wireless-WAN card into
this slot.
12
SSD slot (internal)
No
Insert a SSD into this slot.
13
P-sensor connector (internal) P-sensor cable The wireless WAN antennas kits
come with the cable. Connect the
cable to the connector.
14
Speaker connector (internal) Speaker cable
The speaker come with the cable.
Connect the cable to the
connector.
15
SIM card board connector
(internal)
SIM card board cable Connect one end to the SIM card
board and the other end to this
connector.
16
USB-C (3.2 Gen 2) connector
(external)
No Connect a USB-C compatible
device to this connector.
17
USB-C (3.2 Gen 2) power
connector (external)
No
Connect a USB-C compatible
device or ac power adapter to this
connector.
Looking up FRU information
For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to:
https://support.lenovo.com/partslookup
Chapter 6. Locations 47
