Removal steps of the LCD unit (for ThinkPad X1 Carbon Gen 11)

Step Screw (quantity) Color

Torque

4

M2.5 × L3.5 mm, flat-head, nylon-coated (4) Black 0.294 Nm

(3.0 kgf-cm)

1190 Keyboard bezel assembly with keyboard

To remove the keyboard bezel assembly, remove these FRUs in order:

• “1010 Base cover assembly” on page 64

• “1020 Built-in battery” on page 66

• “1030 M.2 SSD, bracket, and thermal pad” on page 67

• “1040 Wireless WAN card and bracket (for selected models)” on page 68

• “1050 Pen charger (for ThinkPad X1 Yoga Gen 8 only)” on page 70

• “1060 Pen holder (for ThinkPad X1 Yoga Gen 8 only)” on page 71

90

ThinkPad X1 Carbon Gen 11 and X1 Yoga Gen 8 Hardware Maintenance Manual
