Removal steps of the trackpad (for model without NFC module)

Step Screw (quantity) Color

Torque

1

M2 × L1.8 mm, flat-head, nylon-coated (4) Silver or

Black

0.181 Nm

(1.85 kgf-cm)

Installation steps of trackpad

1. A trackpad jig might come with the trackpad which is used for fixing the location of the trackpad. Attach

the trackpad jig to the trackpad and bend the four angles as shown by arrows below.

2. Install the trackpad with jig as shown.

80 ThinkPad X1 Carbon Gen 11 and X1 Yoga Gen 8 Hardware Maintenance Manual
