1070 Thermal fan assembly

For access, remove this FRU:

• “1010 Base cover assembly” on page 64

Removal steps of the thermal fan assembly

When installing:

• Ensure that the connector is attached firmly.

• Do not press the top of the fan cover and the fan hub.

• Before you attach the fan assembly to the computer, apply thermal grease, at an amount of 0.2 grams, on

the part marked

a as shown in the following illustrations. Either too much or too less application of grease

can cause a thermal problem due to imperfect contact with a component.

1080 Audio board

For access, remove this FRU:

• “1010 Base cover assembly” on page 64

72

ThinkPad X1 Carbon Gen 11 and X1 Yoga Gen 8 Hardware Maintenance Manual
