Miscellaneous parts and other FRUs

FRU descriptions

Self-service CRU Optional-service CRU

Screw and tape kit (for ThinkPad X1 Yoga Gen 8)

• M1.6 x L2.6 (8)

• M2.0 x L1.8 Fine pitch (4)

• M2.0 x L2.2 (5)

• M2.0 x L2.2 Step screw (4)

• M2.0 x L2.7 (10)

• M2.0 x L3.5 (7)

• M2.0 x L4.5 (8)

• M2.5 x L3.0 (6)

• M2.5 x L4.0.(8)

• NFC sponge*

• NFC sponge tape*

• Trackpad mylar

• LCD cabel tape

NO NO

Screw and tape kit (for ThinkPad X1 Carbon Gen 11)

• M2.5 x L2.2 Big hat (4)

• M2.5 x L3.5 (4)

• M1.2 x L1.7 (2)

• M2.0 x L1.8 Fine pitch(0.25) (4)

• M2.0 x L5.5 (3.7+1.8L) Step screw (4)

• M2.0 x L2.8 (18)

• M1.6 x L2.6 (6)

• M2.0 x L2.0 (2)

• M2.0 x L2.2 Big hat (1)

• M2.0 x L4.5 (8)

• NFC sponge*

• NFC sponge tape*

• Trackpad mylar

• LCD cabel tape

NO NO

Label kit

NO NO

*for selected models

Connector and cable guide

This section provides information for Lenovo authorized service technicians to help identify connectors and

cables for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major

FRUs and CRUs (for ThinkPad X1 Yoga Gen 8)” on page 48, and “Major FRUs and CRUs (for ThinkPad X1

Carbon Gen 11)” on page 50.

Note: Depending on your model, some connectors or cables might not be available.

52

ThinkPad X1 Carbon Gen 11 and X1 Yoga Gen 8 Hardware Maintenance Manual
