No. FRU descriptions Self-service CRU Optional-service

CRU

1

LCD unit

Note: LCD unit is a single FRU.

No No

2 Keyboard bezel assembly with keyboard No No

3

Trackpad (for models without NFC)

No No

4

Trackpad (for models with NFC)

No No

5

NFC module* No No

6

Coin-cell battery No No

7

Speaker kit No No

8 Built-in battery No No

9 Thermal fan assembly No No

10

System board

No No

11 Wireless-WAN antenna assembly* No No

12 Base cover assembly Yes No

13

Thermal pad for Wireless-WAN card* No No

14 Wireless-WAN card* Yes No

15 Wireless-WAN card bracket* Yes No

16 Thermal pad for M.2 solid-state drive No No

17 M.2 solid-state drive Yes No

18 M.2 solid-state drive bracket Yes No

19 Audio board No No

20

USB board

No No

21

Touchpad and P sensor cable (for models without

NFC)

No No

22

Touchpad, P sensor, and NFC cable (for models with

NFC)

No No

23

Nano-SIM-card tray*

Yes No

24 Power button with fingerprint reader module No No

25 Fingerprint reader bracket No No

26 Pen holder No No

27 Lenovo Integrated Pen Yes No

28 Pen charger with cable No No

a

Recovery USB* No No

b Power cord Yes No

c

ac power adapter Yes No

d

Miscellaneous parts (See “Miscellaneous parts and

other FRUs” on page 52.)

No No

Chapter 6. Locations 49
