5. Remove the wireless-WAN card:
a. Gently disconnect the wireless cable connectors with your fingers
1 . Then, remove the screw that
secures the wireless-WAN card
2 and the card pops up.
b. Carefully remove the wireless-WAN card out of the slot
3 .
6. Install a new wireless-WAN card:
a. Align the contact edge of the new wireless-WAN card with the key in the slot. Then, carefully insert
the card into the slot at an angle of about 20 degrees
1 and pivot the card downward 2 .
b. Install the screw to secure the wireless-WAN card in place
3 . Connect the wireless cable connectors
to the card
4 . Ensure that you connect the orange cable to the main connector on the card, and the
blue cable to the auxiliary connector on the card.
7. Reinstall the base cover assembly.
8. Turn over the computer. Connect the ac power adapter and all disconnected cables to the computer.
56
X1 Yoga and X1 Carbon User Guide
