Removal procedure
Table 9. Screw specification
Step Screw (quantity) Color Torque
1
M2.5 × 3.5 mm, flat-head, nylon-coated (6) Black 0.29 +/- 0.03 Nm
(3.0 +/-0.3 kgf-cm)
2030 LCD panel and elastic adhesive tapes
For access, remove these FRUs in order:
• “1020 Base cover assembly” on page 62
• “1070 I/O bracket” on page 70
• “1200 LCD unit” on page 83
• “2010 LCD bezel sheet and LCD bezel” on page 85
Table 10. LCD elastic adhesive tapes location
LCD cover assembly material
Panel type
LCD elastic adhesive tapes location
• PC
• Aluminum
• Full High Definition panel
• Low Power Full High
Definition panel
• ePrivacy Full High
Definition panel
Removal procedure
1. Pull out each tape slowly in the direction as shown until the adhesive tapes are all released from LCD
unit.
Note: Do not pull the tapes too fast, otherwise, the tapes might snap.
86
ThinkPad T16 Gen 2 and ThinkPad P16s Gen 2 Hardware Maintenance Manual
