Table 8. System board connector and cable guide (continued)
No.
Connector/feature
Internal cable required
Cable connection
6
Speaker assembly connector
(internal)
Speaker assembly cable The speaker assembly comes with
a cable. Connect the cable to this
connector.
7
Ethernet card connector (internal) Ethernet card cable Connect one end of the Ethernet
card cable to the Ethernet card
board and the other end to this
connector.
8
Wireless-WAN-card slot (internal)
No Insert the wireless WAN card into
this slot.
9
Intel models: USB-C (Thunderbolt
4) connector (external)
AMD models: USB-C (USB 4)
connector (external)
No Connect a USB-C compatible
device or a Thunderbolt 4
compatible device to this
connector.
10
Intel models: USB-C (Thunderbolt
4) connector (external)
AMD models: USB-C (3.2 Gen 2)
connector (external)
No Connect a USB-C compatible
device or a Thunderbolt 4
compatible device to this
connector.
11
HDMI connector (external) No Connect a compatible digital audio
device or video monitor to this
connector.
12
Always On USB-A 3.2 Gen 1
connector (external)
No
Connect a USB-A compatible
device to this connector.
13
Audio connector (external)
No
Connect headphones or a headset
with a 3.5-mm (0.14-inch) and 4-
pole plug to this connector.
14a
M.2 solid-state drive connector
(internal) (for Intel models)
No Insert the M.2 solid-state drive into
this slot.
14b
M.2 solid-state drive connector
(internal) (for AMD models)
No Insert the M.2 solid-state drive into
this slot.
15
Built-in battery connector (internal) No Connect the built-in battery.
16
Memory module slot (internal) (for
Intel models)
NO Insert the memory module into this
slot.
17
Trackpad connector (internal)
Trackpad cable
Connect one end of the cable to
the trackpad and the other end to
this connector.
18
Smart card reader connector
(internal) (for selected models)
Smart card reader cable Connect one end of the cable to
the smart card reader and the other
end to this connector.
19
P-sensor connector (internal) P-sensor cable Connect the P-sensor cable to this
connector.
20
Coin-cell battery connector
(internal)
Coin-cell battery cable The coin-cell battery comes with a
cable. Connect the cable to this
connector.
21
Thermal fan connector (internal) Thermal fan assembly cable The thermal fan assembly comes
with a cable. Connect the cable to
this connector.
Chapter 6. Locations 53
