Step Screw (quantity) Color Torque
1
3
M2 × L2 mm, flat-head, nylon-coated (2) Silver 0.181 Nm
(1.85 kgf-cm)
Step 2. Install the 2242 M.2 solid-state drive and its bracket in reverse order.
Replace the 2280 M.2 solid-state drive
Follow the instructions to replace the 2280 M.2 solid-state drive.
Notes:
• An aluminium foil might wrap the M.2 solid-state drive. To access the M.2 solid-state drive, remove the foil
first. Do not damage the foil and attach it in place before installation.
• There might be thermal pads on the top and under the bottom of the M.2 solid-state drive. When replacing
the M.2 solid-state drive, peel off the thermal pad on the M.2 solid-state drive and attach it in place after
installing the new M.2 solid-state drive. Ensure that the thermal pad under the M.2 solid-state drive stays
in its place and is not removed.
Step 1. Remove the 2280 M.2 solid-state drive as shown below.
Chapter 8. Removing or replacing a FRU 77
