1 GEO label
2 IMEI label
3 Country label 4 Genuine Microsoft label
5 S/N label 6 Service QR code
7 COA label
8 Asset tag
9 USA RTC Battery warning label
M.2 solid-state drive and its bracket (for selected models)
For access, remove this FRU:
• “Base cover assembly” on page 72
Attention: The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and
permanent loss of data.
When handling the M.2 solid-state drive, observe the following guidelines:
• Replace the M.2 solid-state drive only for repair. The M.2 solid-state drive is not designed for frequent
changes or replacement.
• Before replacing the M.2 solid-state drive, make a backup copy of all the data that you want to keep.
• Do not apply pressure to the M.2 solid-state drive.
• Do not touch the contact edge or circuit board of the M.2 solid-state drive. Otherwise, the M.2 solid-state
drive might get damaged.
• Do not make the M.2 solid-state drive subject to physical shocks or vibration. Put the M.2 solid-state drive
on a soft material, such as cloth, to absorb physical shocks.
Replace the 2242 M.2 solid-state drive and its bracket
Follow the instructions to replace the 2242 M.2 solid-state drive and its bracket.
Note: There might be thermal pads on the top and under the bottom of the M.2 solid-state drive. When
replacing the M.2 solid-state drive, peel off the thermal pad on the M.2 solid-state drive and attach it in place
after installing the new M.2 solid-state drive. Ensure that the thermal pad under the M.2 solid-state drive
stays in its place and is not removed.
Step 1. Remove the 2242 M.2 solid-state drive and its bracket as shown below.
76
