This index can also help you determine, during regular servicing, what FRUs are likely to need to be replaced
next.
A numeric error is displayed for each error detected in POST or system operation. In the displays, n can be
any number.
If no numeric code is displayed, check the narrative descriptions of symptoms. If the symptom is not
described there, go to “Intermittent problems” on page 37.
Note: For a device not supported by diagnostic codes in the ThinkPad notebook computers, see the manual
for that device.
Numeric error codes
Symptom or error
FRU or action, in sequence
0177
Bad SVP data, stop POST task—The checksum of the
supervisor password in the EEPROM is not correct.
Replace the system board.
0183
Bad CRC of Security Settings in EFI Variable. Enter the
ThinkPad Setup program. – The checksum of the Security
settings in the EFI Variable is not correct.
1. Run the ThinkPad Setup program. The settings
will be corrected automatically. Then save the
current settings by pressing F10.
2. Replace the system board.
0187
EEAIA data access error - The access to EEPROM is
failed.
Replace the system board.
0188
Invalid RFID Serialization Information Area.
Replace the system board.
0189
Invalid RFID configuration information area - The
EEPROM checksum is not correct.
Replace the system board.
0190
Critical low-battery error
1. Charge the battery.
2. Replace the battery.
0191
System Security - Invalid Remote Change requested.
1. Run the ThinkPad Setup program, and then save
current setting by pressing F10.
2. Replace the system board.
0199
System Security - Security password retry count
exceeded.
1. Run the ThinkPad Setup program. The retry count
will be reset. Then save the current settings by
pressing F10.
2. Replace the system board.
0270
Real Time Clock Error.
Have the computer serviced.
0271
Check Date and Time settings.
1. Run ThinkPad Setup to reset the time and date.
2. Replace the coin-cell battery and run the ThinkPad
Setup program to reset the time and date.
1802
Unauthorized network card is plugged in - Turn off and
remove the network card.
1. Remove the network card.
2. Replace the system board.
1820
More than one external fingerprint reader is attached.
Power off and remove all but the reader that you set up
within your main operating system.
Remove all but the reader that you set up for the
authentication.
32 ThinkPad L14 Gen 5 and ThinkPad L16 Gen 1 Hardware Maintenance Manual
