Figure 43. Remove the hinge cap
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Hinge cap
Remove the LCD module
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 29
“Remove the battery pack” on page 30
“Remove the memory shielding and the memory module” on page 31
“Remove the SSD” on page 32
“Remove the Wi-Fi card” on page 41
“Remove the HDMI bracket” on page 42
“Remove the DC-in bracket” on page 43
“Remove the thermal module” on page 44
“Remove the USB-A bracket” on page 49
“Remove the system board” on page 50
“Remove the hinge cap” on page 53
Step 1. Remove six screws and lift the EDP cable.
Chapter 4. Removing a FRU or CRU 55
