Figure 49. Remove the heat sink
Screw specifications
Number of screws
M2.0 x L4
5
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Heat sink
Thermal module mylar
Remove the fans
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 54
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Peel off the pieces of tape.
Figure 50. Peel off the pieces of tape
Step 3. Disconnect the fan cables from the system board. Remove five screws and then remove the fans.
Chapter 4. Removing a FRU or CRU 59
