“Remove the hinge cover” on page 49
“Remove the LCD bezel” on page 49
Step 1. Remove eight screws and then remove the hinges.
Figure 35. Remove the hinges
Screw specifications Number of screws
M2.0 x L2 8
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Hinges
Remove the LCD panel
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 47
“Remove the hinge cover” on page 49
“Remove the LCD bezel” on page 49
Step 1. Remove the two pieces of removable tape with tweezers.
Note: The removable tape is not reusable. Replace it when replacing related FRUs.
50
Hardware Maintenance Manual
