Remove the heat sink
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 34
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Peel off the pieces of tape.
Figure 13. Peel off the pieces of tape
Step 3. Remove five screws and then remove the heat sink.
Figure 14. Remove the heat sink
Screw specifications Number of screws
M2.0 x L4
5
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Heat sink
Thermal module mylar
Chapter 4. Removing a FRU or CRU 39
