M.2 solid-state drive and heatsink
Prerequisite
Before you start, read Generic Safety and Compliance Notices, and print the following instructions.
Attention: The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and
permanent loss of data. When handling M.2 solid-state drive, observe the following guidelines:
• Replace the M.2 solid-state drive only for upgrade or repair. The M.2 solid-state drive is not designed for
frequent changes or replacement.
• Before replacing the M.2 solid-state drive, make a backup copy of all the data that you want to keep.
• Do not touch the contact edge of the M.2 solid-state drive. Otherwise, M.2 solid-state drive might get
damaged.
• Do not apply pressure to the M.2 solid-state drive.
• Do not make the M.2 solid-state drive subject to physical shocks or vibration. Put the M.2 solid-state drive
on a soft material, such as cloth, to absorb physical shocks.
For access, do the following:
1. Remove the power cord. See “Power cord” on page 46.
2. Remove the computer cover. See “Computer cover” on page 48.
3. Remove the storage drive cage if the SSD is behind the cage. See “Storage drive cage” on page 52.
The following illustration shows the location of the M.2 solid-state drive on the system board.
Chapter 5. Hardware removal and installation 55
