Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Coin-cell battery
Remove the Wi-Fi card
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
Step 1. Disconnect the battery pack cable from the system board and disconnect the antennas from the
Wi-Fi card. Then, insert the pointed tip of the tweezers at a 75°-90° angle into the round hole,
carefully pry up the Wi-Fi card, and remove it.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 11. Disconnect the battery pack cable and antennas and remove the Wi-Fi card
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Wi-Fi card
Remove the 2242 solid-state drive
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
Step 1. Disconnect the battery pack cable from the system board. Then, insert the pointed tip of the
tweezers at a 75°-90° angle into the round hole, carefully pry up the 2242 solid-state drive, and
remove it by pulling it away from the slot.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
34
Lenovo LOQ Essential (15″, 9) Hardware Maintenance Manual
