Figure 39. Lift the tape and remove the hinges from the LCD cover
Step 3. Remove four screws (5) and remove the hinge caps (6).
Figure 40. Remove four screws and remove the hinge caps
Label Thread
Length (mm) Torque (kgf.cm) Quantity
5
M2.0 3.0 1.85 ± 0.15 4
Refer to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Hinge
Hinge cap
Remove the EDP cable
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 29
54
Lenovo LOQ 17IRX10 Hardware Maintenance Manual
