Step 2. Download the tool package and double-click the WinMBDWizard.exe file to run the tool. To
download the tool, go to
https://support.lenovo.com/solutions/HT516532.
Step 3. Follow the on-screen instructions to input the MTM and SN, then select the product name and
keyboard language of the computer.
Step 4. Click Start Update to update the product information.
Step 5. Click Yes in the confirmation window to continue the update.
Step 6. Click Finish to close the tool.
Step 7. Click Yes in the confirmation window to restart the computer and apply the configuration on the
system board.
Note: Do not turn off the computer or disconnect the computer from ac power during the whole
process.
Remove the Type-C bracket
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
“Remove the battery pack” on page 30
“Remove the strip cover” on page 36
“Remove the thermal module” on page 41
“Remove the DC-in bracket” on page 40
“Remove the Wi-Fi card” on page 31
“Remove the 2242 solid-state drive” on page 33
“Remove the DIMM shielding and the memory module” on page 35
“Remove the I/O board” on page 43
“Remove the system board and the I/O cable” on page 44
Step 1. Remove the Type-C bracket (1).
Figure 31. Remove the Type-C bracket
Chapter 4. Removing a FRU or CRU 47
