Screw specifications Number of screws
M2 x L4 4
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
60W battery pack
Remove the 80W battery pack (for selected models)
Make sure the following FRUs (or CRUs) have been removed.
“Remove the deco cover” on page 30
“Remove the lower case” on page 31
Step 1. Disconnect the battery pack cable from the system board. Remove six screws and then remove the
80W battery pack.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 7. Remove the 80W battery pack (for selected models)
Screw specifications Number of screws
M2 x L4 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
80W battery pack
Remove the 2242 solid-state drive (SSD) (for selected models)
Make sure the following FRUs (or CRUs) have been removed.
“Remove the deco cover” on page 30
Chapter 4. Removing a FRU or CRU 33
