Figure 35. Remove two screws and the hinge caps
Screw specifications
Number of screws Torque
M2 × L3 2
1.85 ± 0.15 kgf-cm
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Hinge caps
Remove the LCD cover
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 30
“Remove the LCD module” on page 46
“Remove the LCD bezel” on page 48
“Remove the LCD panel” on page 49
“Remove the camera board” on page 50
“Remove the camera cable” on page 51
“Remove the EDP cable” on page 52
“Remove the hinges” on page 53
“Remove the hinge caps” on page 54
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
LCD cover
Chapter 4. Removing a FRU or CRU 55
