Figure 34. Remove six screws and the hinges
Screw specifications
Number of screws Torque
M2.5 × L2 6
3 ± 0.3 kgf-cm
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Hinges
Remove the hinge caps
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 30
“Remove the LCD module” on page 46
“Remove the LCD bezel” on page 48
“Remove the LCD panel” on page 49
“Remove the hinges” on page 53
Step 1. Remove two screws and remove the hinge caps.
54
Hardware Maintenance Manual
