Figure 25. Remove the system board
Screw specifications Number of screws
M2 x L3 2
M2 x L8 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
System board
Use a Golden Key U1 tool to flash-write key id information
After replacing the system board and re-assembling the computer, use a pre-made Golden Key U1 tool to
start the computer and flash-write the serial number (SN), machine type (MT), product name (PN), and UUID
to the new system board.
The Golden Key U1 tool is prepared by running the U1 Update software on a FAT32-formatted USB thumb
drive. Go to
http://support.lenovo.com/us/en/solutions/HT506954 for detailed instructions on how to create
and use a Golden Key U1 tool.
Remove the LCD module
Make sure the following FRUs (CRUs) have been removed.
“Remove the deco cover” on page 30
“Remove the lower case” on page 31
“Remove the 60W battery pack (for selected models)” on page 32
“Remove the 80W battery pack (for selected models)” on page 33
“Remove the 2242 solid-state drive (SSD) (for selected models)” on page 33
“Remove the 2280 solid-state drive (SSD) (for selected models)” on page 34
“Remove the thermal module” on page 35
“Remove the DC-in bracket” on page 36
“Remove the memory module” on page 37
“Remove the Wi-Fi card” on page 39
Chapter 4. Removing a FRU or CRU 47
