Connectors and slots
• Power connector
• Combo audio jack
• Ethernet connector
• HDMI 2.1 connector
• USB Standard-A connector × 2
– Supports SuperSpeed USB 5 Gbps and backwards compatible with USB 2.0.
– Power output up to 5V and 0.9 A
• USB Standard-A connector (with Always-On function)
– Power output up to 5 V and 2 A
• USB Type-C connector (rear)
– Power input up to 20 V and 6.75 A
– Power output up to 5 V and 3 A
– DisplayPort 1.4 compliant in DisplayPort Alt Mode
– Supports SuperSpeed USB 10 Gbps; backwards compatible with SuperSpeed USB 5
Gbps and USB 2.0.
• USB Type-C connector (left)
– Power output up to 5 V and 3 A
Note: If external power is supplied through the rear USB Type-C connector, the
maximum current for this connector is 0.9 A.
– DisplayPort 1.4 compliant in DisplayPort Alt Mode
– Supports SuperSpeed USB 10 Gbps; backwards compatible with SuperSpeed USB 5
Gbps and USB 2.0.
• USB Type-C connector (left, Thunderbolt 4 or USB4 enabled)
– Power output up to 5 V and 3 A
– Up to 40 Gbps data transfer rate in Thunderbolt Alt Mode
– DisplayPort 1.4 compliant in DisplayPort Alt Mode
Note: This port does not support video output when the computer is working in discrete
graphics card only mode.
– Supports SuperSpeed USB 10 Gbps; backwards compatible with SuperSpeed USB 5
Gbps and USB 2.0.
Note: Data rates and performance ratings are dependent on connected devices and cables if
they are used. USB Type-C connectors that are DisplayPort 1.4 compliant through DisplayPort
alternate mode provide maximum output resolution of 5120 x 3200, at 60 Hz frame rate and
color depth of 24 bpp (bits per pixel). The actual maximum output resolution is dependent on
the connected display device and the cable being used.
Security
• UEFI/BIOS passwords
– Administrator password
– User password
– Master hard disk password
– User hard disk password
Network
• Ethernet (10/100/1000 Mbps) network adapter
• Bluetooth and Wi-Fi combo adapter
Chapter 1. Meet your computer 9
