Figure 36. Remove two screws and remove the camera bracket
Screw specifications
Number of screws
M2 x L2.3 2
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Camera bracket
Removable tape
Remove the microphone rubber
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 46
“Remove the LCD bezel (with removable tape)” on page 49
“Remove the LCD panel” on page 49
“Remove the camera bracket” on page 50
Step 1. Remove the microphone rubber.
Figure 37. Remove the microphone rubber
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Microphone rubber
Removable tape
Chapter 4. Removing a FRU or CRU 51
