Introduction 3
Lenovo IoT520
1.2 Specifications
System Core
Processor
Intel® Atom X7-E3950/Atom X5-E3930
Chipset SoC
Video 1 x DisplayPort 1.2 (supports DP++)
Memory
2 GB DDR3L 1600 MHz SODIMM module
(Up to 8 GB support)
I/O Interface
Ethernet 2 x GbE ports(2 x Intel I210IT/ co-lay with I210AT)
Serial Ports 2 x BIOS-configurable RS232/422/485(COM1 to COM2)
USB 2 x USB 3.0 ports + 2 x USB 2.0 ports
Audio Optional 1 mic-in and 1 line-out/speaker
Mini PCIe 2x full size mini PCIe card slots
USIM 1 x USIM socket for 3G/4G LTE communication
WDT Watchdog timer support from SEMA 3.5
Internal I/O
extension
2 x I2C wafer connector, 1 x UART wafer connector, 1 x
USB2.0 wafer connector, 1 x USB 2.0 type A dongle
Power Supply
DC Input
Built-in 6 to 36 VDC wide-range DC input
3P pluggable connectors with latch (GND, V-, V+)
AC Input Optional 90W external AC/DC adapter for AC input
Storage
mSATA 1x mSATA slot with full size mini PCIe
SATA
Optional 1 x 2.5" SATA SSD (connected via internal SATA
wafer)
Micro SD 1 x micro SD slot (Up to 32GB)
Physical
Dimensions 140 (W) x 110 (D) x 58 (H) mm (5.5" x 4.3" x 2.3")
Weight 0.95 kg (2.06 lb.)
Mounting DIN rail, optional wall-mount kit
Environmental
Operating
Temperature
0°C to 50°C (w/ DC source)
0°C to 40°C (w/ AC/DC adaptor)
