“Remove the Wi-Fi card” on page 35
“Remove the heat sink” on page 40
“Remove the fan” on page 37
Step 1. Remove three screws and open the hinge.
Figure 32. Remove three screws and open the hinge
Screw specifications
Number of screws
M2.5 × L4 3
Step 2. Disconnect cables connected to the system board. Disconnect the I/O board cable from I/O board.
Note: For selected models, you may also need to disconnect the fingerprint reader cable from the
system board.
Figure 33. Disconnect cables
48 IdeaPad Slim 5 (14″, 8), IdeaPad Slim 5i (14″, 8), IdeaPad Slim 5 (16″, 8), and IdeaPad Slim 5i (16″, 8) Hardware Maintenance
Manual
