Screw specifications Number of screws
M1.6 × L1.5 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Fingerprint reader bracket
Remove the fingerprint reader board
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the battery pack” on page 29
“Remove the fingerprint reader bracket” on page 46
Step 1. Disconnect the fingerprint reader cable from the fingerprint reader board. Then, remove the
fingerprint reader board.
Figure 31. Disconnect the fingerprint reader cable and remove the fingerprint reader board
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Fingerprint reader board
Remove the system board
Remove the system board and I/O board cable (for 14–inch models)
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the battery pack” on page 29
“Remove the solid-state drive” on page 31
Chapter 4. Removing a FRU or CRU 47
