Figure 20. Disconnect the battery pack cable and peel off the mylar
Step 2. Disconnect the fan cable and remove four screws. Then, remove the fans.
Figure 21. Remove the fans
Screw specifications Number of screws
M2 × L3.5 4
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Fans
Remove the heat sink
Make sure the following FRUs (or CRUs) have been removed.
40
IdeaPad Slim 5 (14″, 8), IdeaPad Slim 5i (14″, 8), IdeaPad Slim 5 (16″, 8), and IdeaPad Slim 5i (16″, 8) Hardware Maintenance
Manual
