“Remove the solid-state drive (SSD) plate” on page 30
Step 1. Remove one screw and then remove the SSD by pulling it away from the slot.
Figure 11. Remove the SSD
Screw specifications Number of screws Torque force (kgf.cm)
M2 x L2.5 1 1.85±0.15
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Solid-state drive (SSD)
Remove the Wi-Fi card
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Detach the main and auxiliary antenna cable connectors. Remove one screw and then remove the
Wi-Fi card by pulling it away from the slot.
Chapter 4. Removing a FRU or CRU 31
