10. Technical data
Design and
mechanics
EVF200 / EVF300
Material Painted aluminium and stainless steel
Color RAL9016S “Trac White”
Weight EVF200B-A4BC: approx. 41 kg
EVF200B-B4BC: approx. 42 kg
EVF300: approx. 68 kg (distribution cabinet empty)
Ingress Protection IP54
Impact resistance
IK10
Operating
temperature
-25 °C … +50 °C
Standard IEC 61851-1, general requirements for electric vehicle conductive charging
system
Approvals CE
Safety features EVF200 / EVF300
Over current
protection (MCB)
32 A (C-curve)
Residual current
protection (RCD)
Type A (30mA AC)
Residual current
detection RCMB
6mA DC
Overvoltage and
undervoltage protection
Congurable
Control voltage
12 VDC
Temperature control High operating temperature, such as direct sunlight, can cause reduced
charging current or temporary interruption in the charging procedure
Optional features
Remotely controlled and monitored RCD reclosing functionality (ARD)
Electrical connections EVF200 / EVF300
Nominal supply voltage
1-ph/3-ph, 230/400VAC
Nominal frequency AC 50 Hz
Nominal supply current
3× 63A
Charging power (nominal)
22kW per charging outlet, 2x 3 x 32A
Supply connections and
terminals
L1, L2, L3, N, PE
Cu 2.5–50 mm² (according to supply current and local regulations)
Tightening torque: 4 Nm (2.5 - 4 mm²), 10 Nm (6 - 50 mm²)
