Digital Hybrid Wireless Belt-Pack Transmitters
Rio Rancho, NM 25
Transmitter
Operating frequencies:
SMWB/SMDWB:
Band A1: 470.100 - 537.575
Band B1: 537.600 - 607.950
SMWB/E01 and SMDWB/E01:
Band A1: 470.100 - 537.575
Band B1: 537.600 - 607.900
614.100 - 614.375
Band C1: 614.400 - 691.175
SMWB/E06 and SMDWB/E06:
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
NOTE: It’s the user’s responsibility to select the approved
frequencies for the region where the transmitter is operating
Channel Spacing: Selectable; 25 or 100 kHz
RF Power output: SMWB/SMDWB, /X: Switchable; 25, 50
or 100 mW
/E01: Switchable; 10, 25 or 50 mW
/E06: Switchable; 25, 50 or 100 mW EIRP
Compatibility Modes: SMWB/SMDWB: Nu Hybrid, Mode 3, IFB
/E01: Digital Hybrid Wireless
®
(EU Hybr),
Mode 3, IFB
/E06: Digital Hybrid Wireless
®
(NA Hybr),
IFB
/X: Digital Hybrid Wireless
®
(NA Hybr), 200
Series, 100 Series, Mode 3, Mode 6, IFB
Pilot tone: 25 to 32 kHz
Frequency stability: ± 0.002%
Spurious radiation: Compliant with ETSI EN 300 422-1
Equivalent input noise: –125 dBV, A-weighted
Input level:
If set for dynamic mic: 0.5 mV to 50 mV before limiting
Greater than 1 V with limiting
If set for electret lavaliere mic
: 1.7 uA to 170 uA before limiting
Greater than 5000 uA (5 mA) with limiting
Line level input: 17 mV to 1.7 V before limiting
Greater than 50 V with limiting
Input impedance:
Dynamic mic: 300 Ohms
Electret lavaliere: Input is virtual ground with servo adjusted
constant current bias
Line level: 2.7 k ohms
Input limiter: Soft limiter, 30 dB range
Bias voltages: Fixed 5 V at up to 5 mA
Selectable 2 V or 4 V servo bias for any
electret
lavaliere
Gain control range: 44 dB; panel mounted membrane switches
Modulation indicators: Dual bicolor LEDs indicate modulation
–20, -10, 0, +10 dB referenced to full
modulation
Controls: Control panel w/ LCD and 4 membrane
switches
Low frequency roll-o: Adjustable from 35 to 150 Hz
Audio Frequency Response: 35 Hz to 20 kHz, +/-1 dB
SMWB/SMDWB/EO1:
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band B2: 563.200 - 639.975
Band C1: 614.400 - 691.175
Band 961: 961.100 - 1014.900
SMWB/SMDWB/EO7-941:
941.525 - 951.975MHz
953.025 - 956.225MHz
956.475 - 959.825MHz
Specications
(Note: the dual envelope “soft” limiter
provides exceptionally good handling
of transients using variable attack
and release time constants. The gradual
onset of limiting in the design begins below full modulation,
which reduces the measured figure for SNR without limiting by 4.5 dB)
SmartNR No Limiting w/Limiting
OFF 103.5 108.0
NORMAL 107.0 111.5
FULL 108.5 113.0
Signal to Noise Ratio (dB):
(overall system, 400 Series mode)
Total Harmonic Distortion: 0.2% typical (400 Series mode)
Audio Input Jack: Switchcraft 5-pin locking (TA5F)
Antenna: Flexible, unbreakable steel cable.
Battery: AA, disposable, Lithium recommended
+1.5VDC
Battery Life w/ AA:
SMWB (1 AA): 4.4hrs
SMDWB
(2 AA):
11.2
hrs
Weight w/ battery(s): SMWB: 3.2 oz. (90.719 grams)
SMDWB: 4.8 oz. (136.078 grams)
Overall Dimensions: SMWB: 2.366 x 1.954 x 0.642 inches;
(without microphone) 60.096 x 49.632 x 16.307 mm
SMDWB: 2.366 x 2.475 x 0.642 inches;
60.096 x 62.865 x 16.307 mm
Emission Designator: SMWB/SMDWB/E01, E06 and E07-941:
110KF3E
SMWB/SMDWB/X: 180KF3E
Recorder
Storage media: microSDHC memory card
File format: .wav files (BWF)
A/D converter: 24-bit
Sampling rate: 44.1 kHz
Input Type: Analog mic/line level compatible;
servo bias preamp for 2V and 4V lavaliere
microphones
Input level: • Dynamic mic: 0.5 mV to 50 mV
• Electret mic: Nominal 2 mV to 300 mV
• Line level: 17 mV to 1.7 V
Input connector: TA5M 5-pin male
Audio Performance
Frequency response: 20 Hz to 20 kHz; +0.5/-1.5 dB
Dynamic range: 110 dB (A), before limiting
Distortion: < 0.035%
Operating temperature range
Celsius: -20 to 40
Fahrenheit: -5 to 104
Specifications subject to change without notice.
Available Recording Time
Using a microSDHC memory card, the approximate
Recording times are as follows. The actual time may
vary slightly from the values listed in the tables.
*microSDHC Logo is
a trademark of SD-3C, LLC
(HD mono mode)
Size Hrs:Min
8GB 11:12
16GB 23:00
32GB 46:07
