LMb, LMb/E01, LMb/E06, Lmb/X
LECTROSONICS, INC.
18
Specications and Features
Operating Frequencies:
US: Band A1: 470.100 - 537.575
Band B1: 537.600 - 607.950
E01: Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band 606: 606.000 - 631.500
Band C1: 614.400 - 691.175
E06: Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
X: Band A1: 470.100 - 537.575 MHz
Band B1: 537.600 - 614.375 MHz
Band C1: 614.400 - 691.175 MHz
NOTE: It’s the user’s responsibility to select the
approved frequencies for the region where the
transmitter is operating
Frequency Selection Steps: Selectable; 100 kHz or 25 kHz
RF Power output: US: 50 mW
E01: 50 mW
E06: 100 mW EIRP
X: 50 mW
Compatibility Modes: US: Nu Hybrid, Mode 3, IFB
E01: Digital Hybrid, IFB
E06: 100 Mode, 200 Mode, Mode 3,
Digital Hybrid, IFB, Mode 6, Mode 7
X: 100 Mode, 200 Mode, Mode 3,
Digital Hybrid, IFB, Mode 6, Mode 7
Pilot tone: 25 to 32 kHz; 5 kHz deviation (
Digital Hybrid mode
)
3.5 kHz deviation (Nu Hybrid)
Frequency Stability: ± 0.002%
Spurious radiation: US: Compliant with ETSI EN 300 422-1 v1.4.2
E01/E06/X: 60 dB below carrier
Equivalent input noise: –120 dBV (A-weighted)
Input level: Nominal 2 mV to 300 mV, before limiting;
Greater than 1V maximum, with limiting
Input impedance: US: 2k Ohm
E01/E06/X: Mic: 300 Ohm, Line: 2k Ohm (for
E01/E06/X)
Input limiter: DSP controlled, dual envelope “soft” limiter
with greater than 30 dB range
Gain control range: 44 dB; digital control
Modulation indicators: • Dual bicolor LEDs indicate modulation of
-20, -10, 0 and +10 dB referenced to full
modulation
• LCD bar graph
For body worn operation, this transmitter model has been tested and meets the FCC RF exposure
guidelines when used with the Lectrosonics accessories supplied or designated for this product.
Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Contact
Lectrosonics if you have any questions or need more information about RF exposure using this
product..
This device complies with FCC radiation exposure limits as set forth for an uncontrolled
environment. This device should be installed and operated so that its antenna(s) are not co-
located or operating in conjunction with any other antenna or transmitter.
This device complies with Industry Canada radiation exposure limits as set forth for a controlled
“professional” use only.
Cet appareil est conforme avec les normes d’Industrie Canada concernant les limites
d’exposition aux radiations pour un usage professionnel contrôlé seulement.
Operating temp. range:
Celsius: -20° - 40°
Farenheit: -5° - 104°
Audio Performance:
Frequency Response: 90 Hz to 20 kHz (+/-1dB) - NuHybrid
70 Hz to 20 kHz (+/-1dB) - Digital Hybrid
Low frequency roll-off: –12 dB/octave; 70 Hz - Nu Hybrid
THD: 0.2% (typical)
SNR at receiver output:
Note: The dual envelope “soft”
limiter provides exceptionally good
handling of transients using variable
attack and release time constants. Once activated, the limiter compresses
30+ dB of transmitter input range into 4.5 dB of receiver output range, thus
reducing the measured figure for SNR without limiting by 4.5 dB
SmartNR No Limiting w/Limiting
OFF 103.5 108.0
NORMAL 107.0 111.5
FULL 108.5 113.0
Controls: • Top panel slide switch; programmable as
power, mute, talkback or no (off) function
• Side panel membrane switches with LCD
interface for power on/off and all setup and
configuration controls
Audio Input Jack: Switchcraft 5-pin locking (TA5F)
Antenna: Galvanized steel, flexible wire
Battery: Two AA lithium
Battery Life: Duracell Ultra: 7 hours
Weight: 5 ounces (141 grams), including lithium
AA batteries and wire belt clip
Dimensions: 3.2 x 2.4 x .8 in. (81 x 61 x 20 mm)
Emission Designator: 110KF3E (US)
180KF3E (E01, E06)
Specifications subject to change without notice.
