HMa, HMa-941, HMa/EO1, HMa/E02, HMa/E06, HMA/E07-941, HMa/X
LECTROSONICS, INC.
16
Operating temp. range: Celsius: -20° - 40°
Farenheit: -5° - 104°
Modulation indicators: Dual bi-color LEDs indicate
modulation of -20, -10, 0, +10 dB
referenced to full modulation
Audio Performance (overall system):
Frequency Response: 35 Hz to 20 kHz (+/-1dB);
Low frequency Roll-o: Adjustable for -3dB @30, 50, 70, 100, 120 or
150 Hz)
THD: 0.2% (typ. 100 Hz to 20 kHz - see table)
Signal to Noise Ratio (dB) at receiver output:
Note: The dual envelope “soft” limiter provides exceptionally good handling of
transients using variable attack and release time constants. Once activated, the
limiter compresses 30+ dB of transmitter input range into 4.5 dB of receiver output
range, thus reducing the measured gure for SNR without limiting by 4.5 dB.
Input Dynamic Range: 125 dB (with full Tx limiting)
Controls & Indicators: • Power/Phantom “ON-OFF”
• Phantom voltage selector
• Audio input gain
• LCD w/membrane switches
• LED audio level indicators
Audio Input Jack: Standard 3-pin XLR (female)
Phantom Power: 5V @ 18 mA max., 15V @ 15 mA
max. and 48 V @ 4 mA max.,
plus “OFF”
USB port: Used for rmware updates
IR (infrared) port: For quick setup by transferring
settings from an IR enabled receiver
Antenna: Housing and attached microphone
form the antenna
Battery: Two 1.5 Volt AA alkaline
Battery Life (Duracell Ultra):
AA alkaline; No Phantom Power: 5h 0m*
AA alkaline; 48V Phantom Power: 3h 30m**
* Tested with a dynamic microphone
** Tested with a Sanken CS1 for a phantom-powered microphone
Weight: 6.7 oz (190 grams) without batteries
Dimensions: 4.25x1.62x1.38 inches
107.95x41.15x35.05 mm
Emission Designator: A1: 44K3F3E
B2: 57K9F3E
HMa/E06: 180KF3E
HMa/E07-941: 110KF3E
Specications subject to change without notice.
Operating Frequency Range:
HMa: Band A1: 470.100 - 537.575
Band B1: 537.600 - 607.950
HMa/X: Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
HMa/E01: Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band 606: 606.000 - 631.500
Band B2: 563.200 - 639.900
Band C1: 614.400 - 691.175
HMa/E02: Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
Band C2: 640.000 - 713.900
HMa/E06: Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
HMa-941: 941.525 - 951.975
952.875 - 956.225
956.475 - 959.825
HMa/E07-941: 941.525 - 951.975
953.025 - 956.225
956.475 - 959.825
NOTE: It’s the user’s responsibility to select the
approved frequencies for the region where the
transmitter is operating
Frequency Selection Steps: Selectable; 100 kHz or 25 kHz
RF Power output: HMa: Selectable 100 or 50 mW
HMa/E01: Selectable 25 or 50 mW
HMa/E02: 10 mW
HMa/E06: Selectable 50
or 100 mW EIRP
HMa/E07-941: Selectable 50 or 100 mW
HMa-941: Selectable 50 or 100 mW
Compatibility Modes: HMa: Nu Hybrid, Mode 3, IFB Mode
HMa/E01: Digital Hybrid, Mode 3, IFB Mode
HMa/E02: Digital Hybrid, Mode 3, IFB Mode
HMa/E06: Digital Hybrid,Mode 3, IFB Mode
HMa/E07-941, HMa-941: Nu Hybrid, IFB Mode
HMa/X: Digital Hybrid, Mode 3, 200 Mode, 100
Mode, Mode 7, Mode 6, IFB Mode
Pilot tone: 25 to 32 kHz; 5 kHz deviation
(in the Digital Hybrid mode)
Frequency stability: ± 0.002%
Spurious radiation: HMa/E01/E02/941/X:
60 dB below carrier
HMa:
Compliant with ETSI EN
300 422-1 v1.4.2
Equivalent input noise: –125 dBV (A-weighted)
Input level: Nominal 2 mV to 300 mV, before limiting.
Greater than 1V maximum, with limiting.
Input impedance: 1K Ohm
Input limiter: Dual envelope “soft” limiter; greater
than 30 dB range
Gain control range: 55 dB; panel mounted
membrane switches
Specications and Features
SmartNR no limiting w/limiting
OFF 103.5 108.0
NORMAL 107.0 111.5
FULL 108.5 113.0
