EQ SETTINGS BASS EQ G: +/- 15dB Bass frequency gain from -15dB to +15dB

f: 60Hz / 80Hz / 100Hz / 200Hz Setting the bass frequency

MIDDLE EQ G: +/- 15dB Centre frequency gain from -15dB to +15dB

f: 500Hz / 1000Hz / 1500Hz /

2500Hz

Setting the centre frequency

Q: 0.50 / 0.75 / 1.00 / 1.25 Setting the Q-factor

TREBLE EQ G: +/- 15dB Treble frequency gain from -15dB to +15dB

f: 10.0kHz / 12.5kHz / 15.0kHz

/ 17.5kHz

Setting the treble frequency

EXIT EQ

SETT.

Exit equalizer menu (press encoder)

EXIT AUDIO SETT. Exit sub-menu (press encoder)

INDIVIDUAL USERNAME (NAME)

Press the transmitter's rotary-push encoder (MENU) to enter the main menu, then turn the encoder to select NAME (highlighted) and press the

encoder to conrm. Now set the individual name (up to 8 digits) by turning the encoder to select a letter, character or number for the rst digit of

the name and conrm by pressing the encoder. This is followed by the input for the second digit and so on. Once the name is complete, press the

encoder again to conrm. Briey (!) press POWER to return directly to the main display; after about 12 seconds of inactivity the main display will

appear automatically.

SET THE DISPLAY BRIGHTNESS (BRIGHTNESS)

Press the transmitter's rotary-push encoder (MENU) to enter the main menu, then turn the encoder to select BRIGHTNESS (highlighted) and press

the encoder to conrm. Select the 3-step display brightness (HIGH = high, MID = medium, LOW = low) by turning the encoder as desired and press 2x

on the encoder to conrm. Briey (!) press POWER to return directly to the main display; after about 12 seconds of inactivity the main display will

appear automatically.

LOCK OPERATING ELEMENTS (PANEL LOCK)

Press the transmitter's rotary-push encoder (MENU) to enter the main menu, then turn the encoder to select PANEL LOCK (highlighted) and press the

encoder to conrm. To lock the control elements, select ON by turning the encoder and press the encoder twice to conrm. Briey (!) press POWER

to return directly to the main display; after about 10 seconds of inactivity the main display will appear automatically. If one of the POWER controls or

the MENU rotary-push encoder is pressed, "PANEL LOCK ON" briey appears on the display and setting changes are blocked. To unlock the controls,

press and hold the rotary-push encoder for about 2 seconds and select OFF in the PANEL LOCK menu item to permanently allow operation using the

controls.
