23
HANDHELD TRANSMITTER
1
2
34
5
1
ON / OFF
On or off switch. Slide the switch upwards to switch the handheld transmitter on; the word „ON“ can
now be read below the switch. Slide the switch downwards to switch the hand-held transmitter off (OFF).
2
STATUS LED
If the charging status of the inserted batteries is sufficient, the LED lights up green when the handheld
transmitter is switched on. If the LED lights up red, the charging status is low. Replace the used batteries
immediately.
3
IR INTERFACE
The infrared interface for synchronising the radio channel of the receiver and transmitter is located on
the underside of the handheld transmitter (for synchronisation procedure, see RECEIVER MODULE – SYNC).
4
SENSITIVITY CONTROL (INPUT SENSITIVITY)
Turn to the left: Decrease the input sensitivity
Turn to the right: Increase the input sensitivity
5
HF SWITCH (SETTING THE TRANSMISSION POWER)
Position „H“: high; Position „L“: low
REPLACING THE BATTERIES
To replace the batteries, open the battery compartment
of the handheld transmitter by loosening the battery
compartment cover by turning it counterclockwise and
pulling it off the housing. Remove the used batteries
and insert fresh batteries (2 x type AA / LR6, alkaline)
according to the illustrations in the battery compartment.
Place the battery compartment cover on the housing
and close the battery compartment by turning it
clockwise. If you are not going to use the transmitter
for a longer period of time, please remove the
batteries to avoid damage to the transmitter
due to leaking batteries.
DEUTSCHFRANCAIS
ESPAÑOL
ENGLISH
ITALIANO POLSKI
