PLEASE NOTE!
To complete the item number for receiver module, handheld and bodypack transmitters, the
suffix corresponding to the desired frequency range must be added when ordering an item.
The suffix B8 corresponds to the frequency range 823 – 832 MHz + 863 – 865 MHz.
The suffix B6 corresponds to the frequency range 655 – 679 MHz.
The suffix B5 corresponds to the frequency range 584 – 608 MHz
The suffix B51 corresponds to the frequency range 514 – 542 MHz (only for the US market)
The suffix B47 corresponds to the frequency range 470 – 490 MHz (only for the US market).
Example: The receiver module with the frequency range 823 – 832 + 863 – 865 MHz
has the article number LDANNYRB8.
TECHNICAL DATA
Item number LDANNY10
General
Product type Battery-powered PA speaker
Type Active
Color Black
System output (RMS) 80 W
System output (Peak) 160 W
Max. SPL Average (Sine burst) 111 dB
Max. SPL Peak (Sine burst) 118 dB
Frequency response (-10 dB) 45 Hz – 20 kHz
Crossover frequency 1800 Hz
Dispersion (H x V) 120° x 60°
Width 361 mm
Depth 300 mm
Height 566 mm
Features TWS, 6-channel mixer with system presets, 3-band EQ, effects (reverb &
delay), priority/ducking mode, USB-C port für mobile device charging
Weight 18.22 kg (15.35 kg without batteries)
Low/mid woofer
Low/mid woofer dimensions 10"
Woofer dimensions (mm) 254 mm
Woofer magnet Ferrite
Woofer brand Custom made
Woofer voice coil 2"
Woofer voice coil (mm) 51 mm
