22
2
Select one of the 12 available radio channels by pressing the arrow keys or repeatedly, if necessary.
3
LED DISPLAY
The selected radio channel is shown in the display (01 – 12).
4
IR
Infrared interface for synchronising the radio channel of the receiver and handheld or pocket transmitter.
5
SYNC
Synchronising receiver and handheld transmitter
To synchronise the radio channel of the receiver and the hand-held transmitter, select the desired radio
channel on the receiver, switch on the hand-held transmitter and then press the SYNC button while
pointing the infrared interface of the hand-held transmitter in direct visual contact with the infrared
interface of the receiver. The infrared interface of the hand-held transmitter is located on the underside
of the hand-held transmitter. If the synchronisation was successful, the red indicator LED RF on the
receiver will now light up.
Synchronising receiver and bodypack transmitter
To synchronise the radio channel of the receiver and the bodypack transmitter, select the desired radio
channel on the receiver, switch on the bodypack transmitter and then press the SYNC button while
pointing the infrared interface of the bodypack transmitter in direct visual contact with the infrared
interface of the receiver. The infrared interface for synchronising the radio channel of the receiver
and transmitter is located in the battery compartment. To open the battery compartment, press both
markings on the sides of the battery compartment cover simultaneously and fold it forwards. If the
synchronisation was successful, the red RF indicator LED on the receiver lights up.
6
RF indicator LED
As soon as there is a radio connection between the transmitter and receiver, the red RF LED lights up.
7
AF indicator LED
The green AF LED indicates an audio signal is present.
8
MUTE LEVEL
CAUTION: Before changing the mute level, first set the volume of the speaker to minimum. The mute function
(noise reduction / squelch) prevents interference noises from occurring when the transmitter is
switched off. In addition, suddenly occurring noise is also suppressed if the signal transmitted from the
transmitter to the receiver is not strong enough (e.g. due to too great a distance between transmitter
and receiver). With the transmitter switched off, adjust the mute level with a suitable screwdriver so
that background noise is just effectively suppressed (turned to the left, noise suppression is reduced,
turned to the right, it is increased). In the case of the setting with strong noise suppression, the
transmission range can be reduced under unfavorable circumstances.The Mute Level control is in the
delivery state on the left stop, the noise suppression thus on minimum strength. This setting is suitable
for the majority of all applications and changes are only required in rare cases.
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
