15
1
POWER INPUT
IEC mains socket with integrated fuse holder. A suitable power cable is included in the delivery.
• Use the mains input to operate and charge the internal batteries at the same time by setting the
POWER switch to the ON position.
• Use the mains input to charge the internal batteries without operating the unit. To do this, set the
POWER switch to the CHARGE position.
WARNING: Replace the fuse only with a fuse of the same type and with the same values. Pay attention
to the imprint on the housing. If the fuse blows repeatedly, please contact an authorised service centre.
2
POWER
Switch in ON position: Unit switched on. The internal batteries can also be charged during operation
using the mains cable supplied.
Switch in OFF position: Unit switched off.
Switch in CHARGE position: Unit switched off and in charging mode.
3
BATTERY
4-segment battery charge status display. 4 LEDs lit = 100 %, 3 LEDs lit = 75 %, 2 LEDs lit = 50 %, 1 LED lit = 25 %.
If only the first LED flashes: Below 10 %. Please connect the unit to the mains immediately for charging.
4
INPUT 1 & 2 – AUDIO INPUT
Audio input for channel 1 or 2, equipped with combo sockets (3-pin XLR / 6.3 mm jack).
The audio inputs are suitable for both balanced and unbalanced cabling.
5
INPUT 1 & 2 – MIC / LINE
Switch for adjusting the input sensitivity for channel 1 or 2.
Connection of a microphone: MIC position.
Connection of a line level player: LINE position.
6
INPUT 1 & 2 – VOLUME
Turn the level control to adjust the volume of channel 1 or 2. Turn counterclockwise: Decrease volume.
Turn clockwise: Increase volume.
7
INPUT 3
Unbalanced stereo line input with a 3.5 mm jack socket for connecting an audio player, e.g. an MP3
player. The input sockets of INPUT 3 and INPUT 4 are wired in parallel and can be used simultaneously.
An incoming stereo signal is internally summed mono.
8
INPUT 4
Unbalanced stereo line input with two RCA sockets for connecting an audio player, e.g. a CD player or
keyboard. The input sockets of INPUT 3 and INPUT 4 are wired in parallel and can be used simultaneously.
An incoming stereo signal is internally summed mono.
9
INPUT 3/4 – VOLUME
Level control to adjust the volume of channel 3 and 4. Turn counterclockwise: decrease volume.
Turn clockwise: Increase volume.
