7
PRELIMINARY OPERATIONS
PACKAGE LIST
The box contains the following:
1x ADA Series amplifier
1x Power cord 3 × 1.5mm
2
16 A Type F
1x Power cord 3 × 1.5mm
2
16 A Type I
1x Power cord 16/3 SJT
1x User Guide
LOCATION
• Install your ADA Series Amplifier in well ventilated rack cabinets at a maximum height of 2 meters
above the floor.
• Secure both front and rear brackets to the rack.
• Connect the AC Mains connector to a circuit breaker.
• Install the amplifier far from EMF emitting devices.
• Avoid placing the amplifier close to heat generating sources.
COOLING
Do not block the ventilation openings and allow a distance of at least 50 cm from the front and rear
ventilation openings of the amplifier. The ADA Series implements a forced-air cooling system to main-
tain constant operating temperatures. Air enters from the front panel and exits from the back of the
amplifier.
The cooling system features variable-speed DC fans controlled by the heat sink mounted sensors.
This ensures that fan noise and internal dust accumulation are kept to a minimum.
In the rare case of overheating, the amplifier is protected by limiting the output power to levels that
can be sustained at the actual ambient temperature.
The ADA Series amplifiers can be stacked one on top of the other, but it is recommended to leave one
rack unit empty every three amplifiers to guarantee adequate air flow.
CLEANING
Use a dry cloth for cleaning the chassis and the front panel. Air filter cleaning should be scheduled in
accordance with the dust levels in the amplifier’s operating environment.
To remove the air filter, detach the front metal cover by unscrewing the two T20 Torx screws (visual
instructions shown below).
Use compressed air to remove dust from the filter or wash it with clean water (let it dry thoroughly
before reinstalling).
AC MAINS SUPPLY
The ADA Series amplifiers implement a universal switching mode power supply, with power factor
correction operating in the range from 100 VAC up to 240 VAC (±10%).
AC mains connection can be found in the rear panel through the IEC C20 inlet. The approved power cord
is provided.
