NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE
CONNECTED TO A POWER SOURCE
Diesel Fired Radiant Heater User’s Manual
© 2020, Lavorwash
18
Parts List: PT-125 SS
# Part Previous Current
1 Fuel Tank Assembly 72-001-0200 01.01.72.012510632
2 Fuel Gauge Assembly 72-022-0130 01.04.72.012510105
3 Fuel Tank Cap Assembly 72-035-0615 70-006-0140
4 Wheel 72-041-1400 01.03.90.003610031
5 Axle 72-041-0200 01.01.72.012510253
6 Wheel Frame 72-042-0120 01.01.72.012510240
7 Drain Bolt 72-002-0220 01.01.72.012510245
8 Transport Handle 72-042-0220 01.01.72.012510238
9 Rear Frame 72-042-0320 38-110-0030
10 Pump Support Plate 72-025-0510 01.01.72.012510232
11 Frame Support N/A N/A
12 Height Adjustment Knob 72-042-0500 01.02.72.012510064
13 Return Fuel Line 72-023-0260 01.03.72.012510050
14 Intake Fuel Line 72-023-0260 01.03.72.012510050
15 Fuel Filter Assembly 72-020-0100 01.02.72.012510062
16 Fuel Pump Assembly 72-027-0100 01.01.72.312520263
17 Main PCB and Fuse 72-025-0450 01.04.72.012520685
18 Intake Fuel Hose 72-023-0310 01.03.72.012510050
19 Tip Over Sensor 75-051-0200 01.04.75.007010149
20 Power Cord 72-032-0200 01.04.72.412520247
21 Power Switch 72-012-0100 01.04.72.312520120
22 Back Cover 72-013-0110 01.02.72.012510061
23 Panel sub-PCB 72-014-0105 01.04.72.012510107
24 Blower Motor 72-045-0100 01.04.72.312520116
24
(internal parts)
Blower Housing
Blower Wheel
Air Guide
N/A
01.01.72.012510230
01.01.72.012510251
01.01.72.012510333
25 Photocell Assembly 72-038-0200 01.04.75.007010083
26 Spark Plug 75-075-0200 01.04.75.007010078
27 Burner Body 72-035-0210 01.01.72.012510250
28 Nozzle 72-036-0100 01.01.72.312520264
29 Burner Blade 72-035-0500 01.01.72.012510635
30 Diffusion Cap 72-036-0200 01.01.72.012510248
31 Ignitor 72-025-0120 01.04.70.104520033
32 Burner Support Plate 72-035-0110 01.01.72.012510331
33 Temperature Overheat Sensor (not shown) 72-040-0120 01.04.72.012510104
34 Radiant Cone Support Assembly 72-035-0680 01.01.72.012510237
35 Radiant Cone Assembly 72-035-0610 01.01.72.012510246
36 Ceramic Fiber 72-035-0610 01.03.72.012510043
37 Heat Plate 72-012-0200 01.09.75.007010002
38 Safety Guard 72-012-0200 01.01.72.012510242
39 Front Frame 72-042-0220 01.01.72.012510238
40 Burner Bracket 72-035-0700 01.01.72.012510234
41 Radiant Visor 72-012-0220 01.01.72.012510225
42 Burner Housing Gasket 72-035-0630 01.03.72.012510046
43 Burner Bracket Gasket 72-035-0630 01.03.72.012510045
44 Burner Head Gasket 72-035-0215 01.03.72.012510047
45 Fuel Pipe Nipple - 01.01.72.012510260
46 Fuel Pump Inlet Pipe - 01.01.72.012510256
