INTENDED USE
• The appliance is intended for professional use.
• Multipurpose steam cleaning equipment. The
unit can be also used as a simple vacuum cleaner
that handles both dust and liquids
• If the device is used for particularly fine powders
(smaller than 0,3 µm), special filters supplied op
-
tionally (Hepa) must be employed.
TECHNICAL DATA
(see technical data plate)
DESCRIPTION AND ASSEMBLY
A Motor head
B
ON/OFF main switch
C “No water” light
D “Steam ready” light
E
ON/OFF boiler switch
F Steam adjustment knob
G Hooks for closing head/drum
J Water tank
J
1
Detergent tank
K Water level sensor
H Vacuum connection
H
1
Nozzle of the flexible hose
H
2
Outlet plug for steam
I Drum
L Flexible hose
L
1
Suction motor button
L2
Steam/Air delivery safety lock
L3
Steam/Air lever
M
Air filter
N
Small nylon brush
N1
Small brass brush
N2
Small S/S brush
O
Extension tube
P
Selector pump switch
I Selector detergent
OFF O
II Selector hot water
only FOAM model:
P1
Use mode selector:
I steam
OFF O
II compressed air
Q
Floor fitting, dry dust (only ETNA)
Q1
Floor fitting, wet liquid (only ETNA)
Q2 Carpet fitting (only ETNA)
Q3 Foaming brush (only FOAM,
do not use with steam)
R Steam pressure gauge
S Round suction brush
S1 Brush for small rectangular nozzle 150
T Big nozzle brush by steam/suction (only ETNA)
T1 Small rectangular nozzle by steam/suction 150
T
2
Armchair small nozzle brush by injection/suction
T3 Big nozzle brush (only FOAM)
T4 Foam tting (only FOAM)
T5 Antifoam additive (only FOAM)
U Window wiper steam/suction
U1
Window wiper for small rectangular nozzle 150
V1 Compressed air tting (only FOAM)
V2 Compressed air pressure gauge (only FOAM)
V3 Compressed air knob (only FOAM)
X Suction flat lance
Y
Accessory connection with steam/suction nozzle
Z Drain hose system
Z1 Filter
Translation of the original instructions
EN
17
