DETERGENT
(see g. A) 2,4 l
Fill the detergent tank with the product re-
commended for the task to be carried out.
• WARNING: Make use only of liquid
detergent, do not absolutely use acid or too
much alkaline products. We suggest you to
make use of our products, which have been
studied for the use with washer machines.
WATER
see g. A) 25 l
see section on "WATER SUPPLY"
only model : Major
- Connect the hose ③⑮,
- turn up the safety catch C2
- then open the steam tap ⑳.
WARNING: Danger from hot steam.
> 1ST START-UP (BEFORE INITIAL USE)
12 V battery model
- Ensure that the main switch ⑩ is set to (0)
OFF
see g. E
- Unscrew the 2 hand screws and lift the cover
away
- Connect the plug to the inverter.
- Position the inverter switch to (I) ON ⑱
- The illuminating “LED” lights up.
- Lower the cover and screw the hand screws
back up.
> Batteria
12 V battery model
- Check the battery charge level and recharge:
- ⑲ when the green "LED" is lit, the battery is
charged
- ⑲ when the yellow "LED" is lit, the battery is
at 50% charge
- ⑲ when the red "LED" is lit, the battery is
discharged
To charge the battery:
- Place the switch to ⑩ (0) OFF
- Connect the plug to the electricity supply
- The charger charges the battery
IMPORTANT: The battery charger works
also with the main switch ⑩ in position (I)
(II) (0).
IMPORTANT: Follow the battery
manufacturer use and safety manual.
> Sand blasting kit
only model " Grati Waster"
(see g. FGHI)
Sand blasting work may be carried out with su-
itable accessories.
- Fill the container with sand (sand not
supplied), sand for blasting, sand calibrated
at Ø 0.5 mm..
IMPORTANT: use dry sand.
> Temperature adjustment
(see g. D)
Adjust the temperature by means of the ther-
mo regulator situated on the control panel.
This machine is equipped with an electronic
thermo regulator to check and adjust the boi-
ler temperature as well as the pressure from
min. 5 bar to max. 10 bar.
- When turning the unit on, the display shows
the temperature reading in the boiler.
Adjust the temperature as follows:
- Hold the ( + ) and ( - ) buttons pressed simul-
taneously for a few seconds;
- Press the ( + ) button to increase the tempe-
rature, or the ( - ) button to decrease it.
It is essential that the thermo regulator is set
to 190°C in order to be able to work at 10
bar.
TABLE OF COMPARISON BETWEEN DEGREES
CENTIGRADE AND STEAM PRESSURE EXPRES-
SED IN BAR
° C bar
152 5
159 6
165 7
170 8
175 9
180 10
• WARNING:
- The machine is pre-set at
the max temperature of 190 °C.
- For any adjustment, timing
or replacement action not
described in this handbook,
EN
21
