NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2020, Lavorwash Kerosene Forced Air Heater User’s Manual
16
# FF215
Part Previous Current
1
Drain Bolt 70-002-0105 01.02.70.012510018
2
Fuel Gauge 70-007-0215 01.04.70.012510020
3
Fuel Filter 70-003-0200 01.02.70.012510020
4
Fuel Cap - Large Plastic 70-006-0140 70-006-0140
5
Power Cord 70-034-0270 01.04.70.412520224
6
Power Switch 70-038-0110 01.04.70.004510015
7
Thermostat Control Knob On PCB On PCB
8
Air Line 70-035-0500 01.03.70.004510005
9
Thermostat Limit Control 70-019-0200 01.04.70.021510031
10
Combustion Chamber Assembly 70-011-0500 70-011-0500
11
Photocell Bracket 70-010-0101 01.01.70.004510020
12
Fuel Line 70-036-0500 70-036-1040
13
Photocell 70-016-0100 01.04.70.004510008
14
Burner Head Assembly 70-014-0401 01.01.70.012510045
15
Nozzle Kit 70-015-0500 70-015-0500
16
Spark Plug Kit 70-052-0200 70-052-0200
17
Motor 70-021-0521 01.04.70.421520220
18
Pump Body 70-020-0401 01.01.70.019010089
19
Rotor Kit 70-022-0200 70-022-0200
20
End Pump Cover 70-020-0102 01.01.70.004510023
21
Filter Kit 70-054-0100 70-054-0100
22
End Filter Cover 70-020-0103 01.02.70.007010022
23
Pump Adjustment Kit 70-055-0100 70-055-0100
24
Capacitor On Motor On Motor
25
Fan 70-016-0220 01.02.70.012510024
26
Ignitor 70-037-0320 01.04.70.104520033
27
Fan Guard 70-016-0220 01.02.70.012510024
28
Main PCB Assembly 70-027-0320 01.04.70.412520222
29
Fuse 70-027-0120 01.04.70.104520039
30
Clip Nut 70-001-0105 70-001-0106
31
Air Pressure Gauge 70-025-0100 01.04.70.007010016
32
Cord Bushing 70-033-0200 01.02.70.012510019
33
Handle N/A N/A
34
Front Handle 70-042-0200 01.01.70.017510082
35
Rear Handle 70-043-0200 01.01.70.017510083
36
Wheel Support Frame 70-041-0201 01.01.70.017510084
37
Wheel Axle 70-041-0205 01.01.70.017510081
38
Wheel 70-041-0150 01.03.90.003610031
39
Wheel Nut 70-041-0550 01.01.70.012510054
40
Hardware Kit (not pictured) 70-056-0210 70-056-0210
41
Cord Wrap 70-032-0200 01.02.70.012510028
42
Motor Supporter 70-020-0610 01.01.70.012510710
43
Motor End Pump Gasket N/A 01.01.70.021510097
44
Pump End Gasket N/A 01.01.70.021510098
