Manual: CS-3000RGB | CS-6000RGB Manual: CS-3000RGB | CS-6000RGB

page 8 / 37 page 9 / 37

English English

6. General Operation

1. Power

Connect the power cord to the device and to the mains. Make sure that your device is pro-

vided with the correct voltage. Wrong voltage could lead to irreparable damages. Please

nd the correct voltage data in the synoptical table at the end of this manual. Make sure

that the device is not directed to people or inammable objects during installation. To

start the device, connect the interlock bridge, insert the key and switch it on, and switch

the device on. The “Emission - Laser on“ LED at the front side of the device begins to

light up when the device is ready for use.

2. Key Switch

There is a key switch at the back of the laser system. Please plug the key to the switch and

turn it on. The laser device only runs when the key is inserted and switched on. Prevent

misuse! Unplug the key when the laser is unattended to prevent misuse of the sys-

tem.

3. Fuse

There is a fuse at the back side of the device. If the fuse should blow, please exchange

it with a new one. If the problems recurs, please contact your dealer or the Laserworld

service department.

4. Modes / Functions

The dierent operation modes can be selected via the four buttons next to the „Set-

tings“ display.

„Enter“ conrms a selection or navigates to the selected menu item.

„Up“ / „Down“ allows for stepping through the current menu or to make a selection.

„Exit“ exits the current menu item and moves one level higher.

4.1. SOUND-TO-LIGHT

Sound-to-light operation allows to playback the integrated patterns to the beat of music or

any noises.

Select „SoUd“ by navigating with the „Up“ / „Down“ buttons and conrm with „Enter“:

Standard selection is „ALL“, which means that all patterns saved on the main board are

played back:

To set the sensitivity of the internal microphone, refer to chapter „4.5. Settings“

4.1. STAND-ALONE / AUTO

Stand-alone or Auto operation allows to random playback the internal patterns.

They are played back according to the internal system settings.

Select „AUto“ by navigating with the „Up“ / „Down“ buttons and conrm with „Enter“:

Standard selection is „All“, which means that all patterns saved on the main board are played

back:

4.1. MASTER-SLAVE

This laser is Master-Slave capable. This means that the Master laser system can hand on a

control signal to one or more Slave lasers, so all do the same.

Master-Slave only works with lasers of the same product series of the same product genera-

tion.

A: Link lasers with DMX cable

To use Master-Slave operation, link the Master with the Slave lasers with DMX cables. Make

sure to use the „DMX out“ port on the Master and the „DMX in“ on the Slave lasers. If several

Slave lasers are used, link the rst one to the Master laser and daisy-chain the control signal

from the rst Slave laser to the second etc..

B: Activate Master Laser

The Master laser needs to be set as control source.

Select „SEt“ by navigating with the „Up“ / „Down“ buttons and conrm with „Enter“:

Use the „Up“ / „Down“ buttons to navigate to „uASt“

Press „Enter“, use the „Up“ / „Down“ buttons to switch the option to „on“ and conrm with

„Enter“

C: Deactivate Master setting on Slave lasers

As soon as the Master option is set to „on“, the laser sends out the control signal for the Slave

units. Make sure that all Slave units have the Master setting set to „oFF“:

• Avoid direct exposure of the laser to

moisture

• Clean the exit window with glass cleaner

from time to time

• Removal of the warranty label as well

as damages to the device caused by

improper handling, neglect of the sa-

fety instructions and service notes will

void the warranty.
