Lantronix TN-SFP-xxx User Guide
33480 Rev. E https://www.lantronix.com/ 15
Vcc
Displays the internally measured transceiver supply voltage. Accuracy is vendor
specific but must be better than 3 percent of the manufacturer's nominal value over
specified operating temperature and voltage. Note that in some transceivers,
transmitter supply voltage and receiver supply voltage are isolated. In that case, only
one supply is monitored. Refer to the device specification for more detail.
Mon1 (Bias)
Displays the measured TX bias current in uA. Accuracy is vendor specific but must
be better than 10 percent of the manufacturer's nominal value over specified
operating temperature and voltage.
Mon2 (TX PWR)
Displays the measured coupled TX output power in mW. Accuracy is vendor specific
but must be better than 3dB over specified operating temperature and voltage. Data
is assumed to be based on measurement of a laser monitor photodiode current. Data
is not valid when the transmitter is disabled.
Mon3 (RX PWR)
Displays the measured received optical power in mW. Absolute accuracy is
dependent upon the exact optical wavelength. For the vendor specified wavelength,
accuracy should be better than 3dB over specified temperature and voltage. This
accuracy should be maintained for input power levels up to the lesser of maximum
transmitted or maximum received optical power per the appropriate standard. It
should be maintained down to the minimum transmitted power minus cable plant loss
(insertion loss or passive loss) per the appropriate standard. Absolute accuracy
beyond this minimum required received input optical power range is vendor specific.
Compliance Information
The fiber optic transmitters on this device meet Class I Laser safety requirements per IEC-825/CDRH standards
and comply with 21 CFR1040.10 and 21CFR1040.11.
WARNING: Visible and invisible laser radiation when open. Do not stare into the beam or view the beam directly
with optical instruments. Failure to observe this warning could result in an eye injury or blindness.
IMPORTANT: Copper based media ports such as Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485, DS1,
DS3, Video Coax, etc., are intended to be connected to intra-building (inside plant) link segments that are not
subject to lightening transients or power faults. Copper-based media ports such as Twisted Pair (TP) Ethernet,
USB, RS232, RS422, RS485, DS1, DS3, Video Coax, etc., are NOT to be connected to inter-building (outside
plant) link segments that are subject to lightening transients or power faults.
Class I Laser Compliance
This product has been tested and found to comply with the limits for FDA Class I laser for IEC60825, EN60825,
and 21CFR1040 specifications.
Translated Safety Warnings
Warning Class I laser product.
Advarsel Laserprodukt av klasse I.
Waarschuwing Klasse-I laser produkt.
Aviso Produto laser de classe I.
Varoitus Luokan I lasertuote.
¡Advertencia! Producto láser Clase I.
Attention Produit laser de classe I
Varning! Laserprodukt av klass I.
Warnung Laserprodukt der Klasse I.
Aviso Produto a laser de classe I.
Avvertenza Prodotto laser di Classe I.
Advarsel Klasse I laserprodukt.
