Lantronix TN-SFP-10G-xx and TN-CWDM-10G-xxx User Guide
33499 Rev. E https://www.lantronix.com/ 4
Product Description
Lantronix TN-SFP-10G-xx and TN-CWDM-10G-xxx TN-SFP-10G-xx and TNCWDM-10G-xxx series Cisco Compatible
10G Small Form Factor Pluggable (SFP+) transceiver modules are designed to install in any SFP+ port. These SFP+
modules allow an interface to the network through the SFP+ connector, and are designed for bi-directional, serial-optical
data communications, at speeds up to 10.5 Gbps.
The Lantronix TN-SFP-10G-xx series 10G SFP+ transceiver modules are designed to install in any SFP+ port allowing for
10GBase-X interfaces to the network through the SFP+ connector. The TN-SFP-10Gxx transceivers are Cisco compatible
and are designed for bi-directional serial-optical data communication such as 10G Ethernet at speeds up to 10.3 Gbps.
Lantronix SFP and SFP+ modules fully comply with the Multi-Sourcing Agreement (MSA). This compliance allows our
SFP+ modules to be used in all other MSA compliant SFP+ platforms. In addition, Lantronix SFP modules are also
compatible with all Cisco SFP+ based routers and switches, as well as Cisco’s IOS software. Lantronix SFP and SFP+
modules ARE NOT Cisco OEM brand modules.
TN-CWDM-10G-1xx0-40 Series: The TN-CWDM-40G-1xx0-40 10G modules are Cisco Compliant* and are designed for
bi-directional serial-optical data communications such as 10G Ethernet. Each X2/XFP/SFP+ operates at a nominal CWDM
wavelength. There are 8 wavelengths available in 20nm steps from 1470nm to 1610nm.
TN-SFP-10G-xR Series: The TN-SFP-10G-xR series 10G SFP+ transceiver modules are designed to install in any SFP+
port allowing for 10GBase-X interfaces to the network through the SFP+ connector. The TN-SFP-10G-xR transceivers are
Cisco Compliant* and are designed for bi-directional serial optical data communication such as 10G Ethernet at speeds
up to 10.3 Gbps.
Features
• SFP+ Optical Transceiver with LC connector
• 10G small Form-Factor Pluggable (SFP+) MSA compatible
• Compliant with IEEE 802.3ae 10GBASE-SR/LR/LW
• SFF-8472 Digital Diagnostic Function (DMI)
• Single +3.3 V Power Supply
• RoHS Compliant (all models)
• Class 1 Laser International Safety Standard IEC 60825 Compliant
Specifications and Standards
The TN-SFP-10G-xxx and TN-CWDM-10G-xxx are designed to meet these standards and specifications:
Standards
IEEE 802.3z, IEEE 802.3ae, 10GBASE-SR/LR/LW, 10GBase-ER/EW, SFF-8472
Digital Diagnostic function (DMI). IEEE 802.3az (TN-SFP-10G-T)
Compliance
RoHS Compliant (all models)
Class 1 Laser International Safety Standard IEC 60825 Compliant
FDA 21; CFR 1040.10 and 1040.11
Dimensions
Width: 0.52” [13 mm] x Depth: 2.18” [55 mm] x Height: 0.33” [8 mm]
Power Input
3.3V
Output Wavelength
-5.5nm < λc < +7.5nm
Shipping Weight
1 lb (16 oz) approximately
Voltage
3.3V
Operating Temp
0°C to +70°C (32°F to 158° F)
Storage Temp
-40°C to +85°C (-40° to 185°F)
Humidity
5% to 95%, non-condensing
Warranty
Lifetime
