Lantronix TN-SFP-10G-xx and TN-CWDM-10G-xxx User Guide
33499 Rev. E https://www.lantronix.com/ 5
Optical Specifications
The Optical Specs for all Lantronix SFPs are listed on the SFP Specifications page.
TN-SFP-10G-x-xx Series
Cisco Compatible 10GBase SFP+ Modules; 10GBase-X, SFP+ With DMI (LC).
#
SKU
Description
1 TN-SFP-10G-D-10
10GBase-BX, SFP+ w/ DMI 1330 TX/1270 RXnm (LC) [10 km/6.2 mi.]
Link Budget: 5.9 dB
2 TN-SFP-10G-D-20
10GBase-BX, SFP+ w/ DMI 1330 TX/1270 RXnm (LC) [20 km/12.4 mi.]
Link Budget: 12.1 dB
3 TN-SFP-10G-D-40
10GBase-BX, SFP+ w/ DMI 1330 TX/1270 RXnm (LC) [40 km/24.9 mi.]
Link Budget: 16.0 dB
4
TN-SFP-10G-D-60
10GBase-BX, SFP+ w/ DMI 1330 TX/1270 RXnm (LC) [60 km/27.3 mi.]
5 TN-SFP-10G-D-80
10GBase-BX, SFP+ with DMI 1550nm TX/1490nm RX single mode (LC)
[80 km/49.7 mi.] Link Budget: 22.0 dB
6 TN-SFP-10G-ER
10GBase-ER, SFP+ w/ DMI 1550nm (LC) [40 km/24.9 mi.]
Link Budget: 15.8 dB
7
TN-SFP-10G-LR
10GBase-LR, SFP+ w/ DMI 1310nm (LC) [10 km/6.2 mi.] Link Budget: 9.0 dB
8
TN-SFP-10G-LRM
10GBase-LRM, SFP+ w/ DMI 1310nm (LC) [220m; 722 ft.] Link Budget: 1.5 dB
9 TN-SFP-10G-SR
10GBase-SR, SFP+ w/ DMI 850nm (LC) [300/82/33 m; 985/269/108 ft.]
Link Budget: 4.0 dB
10 TN-SFP-10G-U-10
10GBase-BX, SFP+ w/ DMI 1270 TX/1330 RXnm (LC) [10 km/6.2 mi.]
Link Budget: 5.9 dB
11 TN-SFP-10G-U-20
10GBase-BX, SFP+ w/ DMI 1270 TX/1330 RXnm (LC) [20 km/12.4 mi.]
Link Budget: 12.1 dB
12 TN-SFP-10G-U-40
10GBase-BX, SFP+ w/ DMI 1270 TX/1330 RXnm (LC) [40 km/24.9 mi.]
Link Budget: 16.0 dB
13
TN-SFP-10G-U-60
10GBase-BX, SFP+ w/ DMI 1270 TX/1330 RXnm (LC) [60 km/37.3 mi.]
14 TN-SFP-10G-U-80
10GBase-BX, SFP+ with DMI 1490nm TX/1550nm RX single mode (LC)
[80 km/49.7 mi.] Link Budget: 23.0 dB
15 TN-SFP-10G-ZR
10GBase-ZR, SFP+ w/ DMI 1550nm (LC) [80 km/49.7 mi.]
Link Budget: 24.0 dB
16
TN-SFP-10G-ZR-
10
10GBase-ZR, SFP+ with DMI 1550nm single mode (LC)
[100 km/62.1 mi.] Link Budget: 26.0 dB
17 TN-SFP-10G-T
Cisco compatible Copper SFP+, designed for 10 Gigabit Ethernet bidirectional
communication. Supports 100M/1G/10G. maximum 30m reach over Cat6a/Cat 7 cable.
Maximum 3.0W power consumption needed; 0 – 70 C temperature range.
Auto‐ negotiates with other 10G‐Base‐T Phys. Auto‐sense MDI/MDIX.
